Aluminium, Commercial Alloy

5454 H22 and H32 Sheet & Plate

Medium-high strength aluminium alloy with exceptional corrosion resistance.

Aluminium alloy 5454 has very good corrosion resistance, in particular to seawater and general environmental conditions. Alloy 5454 is widely used in the manufacture of chemical storage tanks, automotive wheels and in particular those applications that may be subject to temperatures in excess of 65ºC.

DOWNLOAD PDF

Range

PLEASE NOTE

If you do not see what you are looking for, please contact your local service centre with your specific requirements.

5454 H22 and H32 Aluminium Related Specifications

System / Standard Country / Region Grade / Designation
AA USA 5454-H22 / 5454-H32
UNS International A95454 (5454-H22 / 5454-H32)
EN / DIN Europe EN AW-5454-H22 / EN AW-5454-H32
EN Name Europe AlMg3Mn-H22 / AlMg3Mn-H32
BS UK 5454-H22 / 5454-H32 (equivalent use)

Properties

Chemical Composition

Alloy 5454

Chemical Element % Present
Manganese (Mn) 0.50 - 1.00
Iron (Fe) 0.00 - 0.40
Magnesium (Mg) 2.40 - 3.00
Silicon (Si) 0.00 - 0.25
Chromium (Cr) 0.05 - 0.20
Titanium (Ti) 0.00 - 0.20
Zinc (Zn) 0.00 - 0.25
Copper (Cu) 0.00 - 0.10
Other (Each) 0.00 - 0.05
Others (Total) 0.00 - 0.15
Aluminium (Al) Balance

Sheet 0.2mm to 6.0mm thick

Mechanical Property Value
Proof Stress 180 Min MPa
Tensile Strength 250 - 305 MPa
Hardness Brinell 74 HB
Physical Property Value
Density 2.69 g/cm³
Melting Point 645 °C
Thermal Expansion 23.6 x 10-6/K
Modulus of Elasticity 70.5 GPa
Thermal Conductivity 135 W/m.K
Electrical Resistivity 34 % IACS

Applications

Characteristics

Additional Information

Fabrication

Formability of alloy 5454 is good in the softer tempers and it can be extruded.

Alloy 5454 has good weldability by some methods but soldering and brazing are not recommended.
