Aluminium, Commercial Alloy

Aluminium Alloy 6063 T6 Bar & Extrusion

One of the most popular alloys in the 6000 series and most widely known as an architectural alloy.

Aluminium alloy 6063 is a medium strength alloy commonly referred to as an architectural alloy. It is normally used in intricate extrusions and is most commonly supplied in the T6 temper.

DOWNLOAD PDF

Range

Product Form Size Range Size Range
From To
Flat Bar 3⁄8" x 1⁄8" 6" x 1"
Square Box Section 1⁄2" x 1⁄2" x 16swg 4" x 4" x 1⁄4"
Rectangular Box Section 1" x 1⁄2" x 16swg 6" x 3" x 3⁄8"
Tube 3⁄8" OD x 16swg 6 1⁄2" OD x 1⁄4"
Channel 3⁄8" x 3⁄8" x 1⁄16" 10" x 3" x 3⁄8" x 1⁄2"
Equal Angle 3⁄8" x 3⁄8" x 1⁄16" 6" x 6" x 1⁄2"
Unequal Angle 3⁄4" x 1⁄4" x 1⁄16" 6" x 3" x 3⁄8"
Angle (Metric) 25 x 25 x 3mm, 50 x 25 x 3mm, 50 x 50 x 3mm -
Z Section 3⁄4" x 1⁄2" x 1⁄16" 1 3⁄4" x 1" x 1⁄8"

PLEASE NOTE

If you do not see what you are looking for, please contact your local service centre with your specific requirements.

6063 T6 Aluminium Related Specifications

System / Standard Country / Region Grade / Designation
AA USA 6063-T6
UNS International A96063 (6063-T6)
EN / DIN Europe EN AW-6063-T6 / 3.32206
EN Name Europe AlMg0.7Si-T6
GB China 6063-T6
JIS Japan A6063-T6
BS UK 6063-T6 (extruded profiles)

Properties

Chemical Composition

Alloy 6063

Chemical Element % Present
Manganese (Mn) 0.00 - 0.10
Iron (Fe) 0.00 - 0.35
Magnesium (Mg) 0.45 - 0.90
Silicon (Si) 0.20 - 0.60
Zinc (Zn) 0.00 - 0.10
Titanium (Ti) 0.00 - 0.10
Chromium (Cr) 0.00 - 0.10
Copper (Cu) 0.00 - 0.10
Other (Each) 0.00 - 0.05
Others (Total) 0.00 - 0.15
Aluminium (Al) Balance

Rod & Bar Up To 150mm Dia. & A/F

Mechanical Property Value
Proof Stress 170 Min MPa
Tensile Strength 215 Min MPa
Hardness Brinell 75 HB
Elongation A 10 Min %
Elongation A50 mm 8 Min %

Rod & Bar 150mm to 200mm Dia. & A/F

Mechanical Property Value
Proof Stress 160 Min MPa
Tensile Strength 195 Min MPa
Hardness Brinell 75 HB
Elongation A 10 Min %

Tube Up To 25mm Wall Thickness

Mechanical Property Value
Proof Stress 170 Min MPa
Tensile Strength 215 Min MPa
Elongation A50 mm 8 Min %
Hardness Brinell 75 HB
Elongation A 10 Min %

Profiles Up to 10mm Wall Thickness

Mechanical Property Value
Proof Stress 170 Min MPa
Tensile Strength 215 Min MPa
Elongation A50 mm 6 Min %
Hardness Brinell 75 HB
Elongation A 8 Min %

Profiles 10mm to 25mm Wall Thickness

Mechanical Property Value
Proof Stress 160 Min MPa
Tensile Strength 195 Min MPa
Elongation A50 mm 6 Min %
Hardness Brinell 75 HB
Elongation A 8 Min %
Process Rating
Weldability - Gas Good
Weldability - Arc Very Good
Weldability - Resistance Good
Brazability Very Good
Solderability Good

Applications

Characteristics

Additional Information

Weldability
Process Rating
Weldability - Gas Good
Weldability - Arc Very Good
Weldability - Resistance Good
Brazability Very Good
Solderability Good
Process Rating
Workability - Cold Average (Acceptable)
Machinability Good

ຄົ້ນຫາຜະລິດຕະພັນທີ່ທ່ານຕ້ອງການ

ເຄືອຂ່າຍສູນບໍລິການທີ່ກວ້າງຂວາງໃນປະເທດຈີນ, ໂດຍໄດ້ຮັບການສະໜັບສະໜູນຈາກສະຖານທີ່ປຸງແຕ່ງທີ່ເຂັ້ມແຂງ.

Stainless Steel
CNC Routing

DISCLAIMER

This Data is indicative only and as such is not to be relied upon in place of the full specification. In particular, mechanical property requirements vary widely with temper, product and product dimensions. All information is based on our present knowledge and is given in good faith. No liability will be accepted by the Company in respect of any action taken by any third party in reliance thereon. Please note that the ‘Datasheet Update’ date shown above is no guarantee of accuracy or whether the datasheet is up to date.

The information provided in this datasheet has been drawn from various recognised sources, including EN Standards, recognised industry references (printed S online) and manufacturers’ data. No guarantee is given that the information is from the latest issue of those sources or about the accuracy of those sources. Material supplied by the Company may vary significantly from this data but will conform to all relevant and applicable standards. As the products detailed may be used for a wide variety of purposes and as the Company has no control over their use; the Company specifically excludes all conditions or warranties expressed or implied by statute or otherwise as to dimensions, properties and/or fitness for any particular purpose, whether expressed or implied. Advice given by the Company to any third party is given for that party’s assistance only and without liability on the part of the Company. All transactions are subject to the Company’s current Conditions of Sale. The extent of the Company’s liabilities to any customer is clearly set out in those Conditions; a copy of which is available on request.
